IronLift 3000 Electric Counterbalance Forklift
Clean, quiet, and built for the warehouse floor. 3,000 lb electric sit-down forklift.
3,000 lb electric counterbalance sit-down forklift. 48V AC drive, 189-inch lift height, regenerative braking, zero emissions. Ideal for warehouses and distribution centers.
- 3,000 lb rated lift capacity at 24-inch load center
- 189-inch (15.75 ft) maximum lift height — 3-stage full free lift mast
- 48V AC electric drivetrain — zero emissions, approved for indoor use
- Regenerative braking — 8+ hour runtime per charge
- Fingertip hydraulic controls on adjustable armrest
- Full free lift — raises load without extending outer mast (critical for low-clearance areas)
- Overhead guard and integrated backrest standard
- On-board diagnostics with fault code display
✓ In Stock — Ships in 5-10 business days
| Weight | 7,900 lbs (with battery) |
| Battery | 48V / 600Ah (8+ hr runtime) |
| Warranty | 2 years drivetrain, 1 year hydraulics |
| Mast Type | 3-stage full free lift |
| Tire Type | Non-marking cushion (solid) |
| Drive System | 48V AC electric |
| Lift Capacity | 3,000 lbs (at 24" load center) |
| Overall Width | 42 inches |
| Turning Radius | 72 inches |
| Max Lift Height | 189 inches (15.75 ft) |
| Travel Speed (loaded) | 10.5 mph |
Multi-angle views of the IronLift 3000 Electric Counterbalance Forklift. Click any image to zoom.
See this class of lift in action. The video below shows installation, real-world operation, and the kind of shop this lift belongs in.
Forklifts use a hydraulic mast system to raise, lower, and tilt loads on the forks. Electric models use joystick or fingertip controls; LP gas models add engine throttle. Always perform a pre-shift inspection before operation.
🔧 Hydraulic Controls
Three primary hydraulic functions: Lift (raise/lower the mast), Tilt (forward/back tilt of the carriage), and Sideshift (left/right fork movement on equipped models). Controls are fingertip levers or a multi-function mini-lever depending on model. Smooth, deliberate inputs prevent load swing.
🚗 Drive Controls
Direction selector (Forward/Neutral/Reverse) and accelerator pedal control travel. Electric models: smooth pedal engagement. LP gas models: standard accelerator with engine idle. Never shift direction at speed — come to a full stop before changing direction to protect the transmission.
⚠️ Mast Tilt
Tilt the mast back (toward the operator) when traveling with a load — this lowers the center of gravity and reduces tip-over risk. Travel with the load 6–8 inches off the ground. Only tilt forward when placing a load on racking.
🔋 Battery / Fuel Management
Electric: charge the battery fully at end of each shift; never discharge below 20% (reduces battery life). LP gas: swap the tank before the pressure gauge enters the red zone — running the engine on empty causes air intake that can damage the regulator.
⚙️ Stability Triangle
Forklifts balance on a three-point stability triangle formed by the two front drive wheels and the rear steer axle. The center of gravity must remain inside this triangle — front-loading beyond rated capacity, raising the load high while traveling, or turning sharply with a raised load can shift the COG outside the triangle, causing tip-over.
🛡️ Overhead Guard
The overhead guard protects the operator from falling objects when working under racking or placing loads on high shelves. The guard is rated for falling objects, not rollover protection — do not stand on the guard or use it as a work platform. Inspect for cracks or damage before each shift.
🔒 Seatbelt / Operator Restraint
All sit-down counterbalance forklifts are equipped with a lap belt or full restraint system. OSHA 1910.178 requires operators to use the restraint at all times. In the event of a tip-over, the restraint keeps the operator inside the overhead guard zone — the primary survival position.
🚨 Speed & Pedestrian Safety
Forklift-pedestrian collisions are the leading cause of forklift fatalities. Maintain a maximum of 5 mph in pedestrian areas, 3 mph at intersections and blind corners. Pedestrians always have the right of way. Sound the horn at all blind intersections and when entering/exiting loading docks.
How does this compare?
The 3,000 lb class covers the majority of standard pallet and rack load applications — most pallets loaded to 2,000–2,500 lbs fall comfortably within this rating. The key differentiator between budget electric forklifts and this class is the AC drivetrain: DC motors require brush replacement every 2,000–3,000 hours; AC motors are brushless and essentially maintenance-free on the drivetrain side. Full free lift mast is non-negotiable for facilities with low doorways or mezzanine sections — it lets you lift a pallet a full pallet-height before the outer mast starts to extend upward.
