Genie GS-1930 Electric Scissor Lift
The industry benchmark for compact indoor scissor lifts. 19 feet. 32-inch width.
19-ft compact electric scissor lift. 32-inch width fits through doorways, 500 lb capacity, 24V DC zero-emission. Non-marking tires, drive-to-height.
- 19 ft platform height (25 ft working height)
- 500 lb platform rated capacity (2 workers + tools)
- 32-inch overall width — fits through standard single doorways
- Zero-emission 24V DC electric — indoor and food-safe approved
- Drive-to-height capability up to 16 ft
- Non-marking foam-filled tires — safe on polished, epoxy, and tile floors
- Pothole protection auto-engages above 6 ft
- On-board diagnostics with fault code display
✓ In Stock — Ships in 5-10 business days
| Model | GS-1930 |
| Tire Type | Non-marking foam-filled |
| Drive System | 24V DC electric |
| Gradeability | 25% |
| Manufacturer | Genie (Terex) |
| Overall Width | 32 inches (0.81 m) |
| Platform Size | 71" × 29" (1.80 m × 0.74 m) |
| Certifications | ANSI/SAIA A92.20, CE EN 280 |
| Machine Weight | 2,940 lbs (1,334 kg) |
| Working Height | 25 ft (7.62 m) |
| Battery Runtime | 8 hours (typical) |
| Platform Height | 19 ft (5.79 m) |
| Platform Capacity | 500 lbs (227 kg) |
| Pothole Protection | Auto-engages above 6 ft |
Multi-angle views of the Genie GS-1930 Electric Scissor Lift. Click any image to zoom.
See this class of lift in action. The video below shows installation, real-world operation, and the kind of shop this lift belongs in.
⚙️ Pothole Protection Bar
A mechanical bar extends outward from the platform's lower edge when elevated above 6 feet. If the machine approaches a floor opening, drop-off, or dock edge, the bar contacts the hazard before the wheel reaches it — automatically halting drive before a tip-over can occur. Non-defeatable by the operator.
🔒 Outrigger Interlock (RT Models)
Rough-terrain models cannot raise above a set height unless all four outriggers confirm positive ground contact. The interlock is mechanical — not software-only. A single outrigger without firm contact blocks elevation above the threshold, preventing elevation on an unstable base.
🛡️ OSHA-Compliant Platform Guarding
Full-height (43 in) guardrails with mid-rail and toe board meet OSHA 1926.502 and ANSI/SAIA A92.20 fall protection requirements. The self-closing entry gate uses a positive slam-latch that cannot be accidentally kicked open. Platform D-ring anchor for personal fall arrest (on most models).
📊 Load Management System
On-board sensors monitor platform weight continuously. Overloading locks out the lift function and displays a fault code — the machine will not raise until load is reduced to within rating. This protects the scissor mechanism from overload and prevents the stability limit from being exceeded.
How does this compare?
The GS-1930 vs. GS-2032: the 1930 is the go-to when doorways are the constraint — it's 32 inches wide vs. 46 inches for the wider platform 2032. If you need more platform space or higher reach, move up to the 2032 or 2646. For facilities with 36-inch door frames, the 1930 is the only production scissor that clears without removing the doors. For outdoor or rough-surface work, step up to a rough-terrain model — the GS-1930 is slab-only.
