IronMover 6600E Electric Pallet Jack
Walk-behind electric. Move six-thousand-pound loads with a thumb.
6,600 lb walkie electric pallet jack. 24V DC drive, variable speed, on-board 120V charger, electromagnetic brakes. 6+ hour runtime per charge.
- 6,600 lb rated capacity — handles heavy palletized loads effortlessly
- 24V DC electric drive — variable speed with creep mode for precise placement
- On-board 120V charger — overnight charge from any standard outlet
- Electromagnetic brakes — auto-stop when tiller arm is released
- Sealed maintenance-free batteries — 6+ hours per charge
- Dual-tandem polyurethane load wheels for smooth warehouse floor operation
- Horn and reverse warning buzzer standard
- Full-width adjustable tiller arm with ergonomic throttle thumb control
✓ In Stock — Ships in 5-10 business days
| Weight | 820 lbs (with battery) |
| Battery | 24V / 210Ah sealed lead-acid |
| Charger | On-board, 120V / 20A |
| Capacity | 6,600 lbs |
| Warranty | 2 years drivetrain, 1 year battery |
| Fork Width | 27 inches |
| Fork Length | 48 inches |
| Load Wheels | 7" dual-tandem polyurethane |
| Drive System | 24V DC electric motor |
| Travel Speed | 3.7 mph (max) |
| Lowered Height | 7.75 inches |
| Battery Runtime | 6+ hours (typical mixed operation) |
Multi-angle views of the IronMover 6600E Electric Pallet Jack. Click any image to zoom.
See this class of lift in action. The video below shows installation, real-world operation, and the kind of shop this lift belongs in.
Pallet jacks use a hydraulic pump system (manual) or electric motor and hydraulics (powered) to raise pallets a few inches off the floor for transport. Operation is straightforward — the main variables are load limits and floor surface awareness.
🔧 Pump Handle (Manual)
The three-position pump handle controls all motion: pump up to raise the forks, neutral (horizontal) to maintain height, rotate down to lower. Pump 5–10 strokes to reach operating height. The forks only need to clear the ground by 1–2 inches for transport.
🎮 Tiller Controls (Electric)
The tiller arm has a throttle thumb lever (forward/reverse), a lift/lower button, and a horn. Squeeze the tiller handle to enable drive — releasing the handle automatically applies the electromagnetic brake and stops the unit. Creep mode (low-speed position) allows precise pallet placement.
📐 Entering Pallets
Align the forks with the pallet openings before entering. Approach straight — angled entry twists the forks and can split pallet boards. Center the load on the forks; off-center loads shift weight and reduce effective capacity. For floor-level pallets, approach slowly to avoid ramping the fork tips over the bottom board.
🛑 Stopping & Lowering
Manual: rotate handle to lower position; gravity lowers the forks through the hydraulic release valve. Electric: use the lower button or release the tiller to brake, then press lower. Lower the load fully before leaving the jack unattended — never leave a load elevated.
⚙️ Load Capacity Markings
The rated capacity is stamped on the data plate and must not be exceeded. Overloading a manual pallet jack distorts the forks and can cause sudden hydraulic failure. Overloading an electric jack can burn out the drive motor or trigger the overload cutout sensor.
🛡️ Ramp & Incline Safety
Manual pallet jacks are rated for flat floor operation only — do not use on ramps or inclines. Electric walkie jacks have a rated grade (typically 5–10%) — check the data plate. On any grade, always keep the load on the uphill side of the machine to prevent runaway.
🔒 Parking & Unattended Units
Never leave a pallet jack with a load elevated — always lower the forks fully before leaving the machine. For electric units, apply the parking brake (tiller in vertical position) and remove the key when leaving unattended. Block the wheels if parking on any incline.
🚨 Pinch Point Awareness
The area around the forks, wheels, and tiller arm contains pinch and crush points. Keep feet clear of the fork tips when entering pallets. Never position your body between the jack and a fixed object. On electric rider models, the platform area has an auto-cutout if the operator is not on the platform.
How does this compare?
Electric pallet jacks pay for themselves in operations moving 80+ pallets per day. The labor cost savings from reduced operator fatigue, faster travel speeds, and elimination of manual pumping easily justify the price premium over manual jacks within a few months of heavy use. The 6,600 lb capacity class handles essentially any standard pallet load — the step above this is a stand-up rider pallet jack for very long travel distances, and eventually a sit-down counterbalance for loads that exceed standard pallet dimensions.
