Genie IWP-25S Indoor Work Platform
Twenty-five feet of indoor reach. Purpose-built for occupied facility work.
25-ft heavy-duty indoor work platform. 300 lb capacity, continuous position locking, 27×30-inch cage platform, 110V AC. 680-lb unit weight for elevator transport.
- 25 ft platform height (31 ft working height)
- 300 lb single-person capacity with tools
- Continuous-position locking — stop at any foot of height
- 27" × 30" platform cage — more foot room than base models
- 66" × 66" outrigger footprint for full-height stability
- 110V AC electric — plugs into any facility outlet
- Powder-coated aluminum — corrosion-resistant for wet environments
- 680 lb unit weight — standard freight elevator compatible
✓ In Stock — Ships in 5-10 business days
| Drive | Manual push |
| Model | IWP-25S |
| Mast Type | Multi-section telescoping aluminum |
| Lift Power | 110V AC electric |
| Manufacturer | Genie (Terex) |
| Platform Size | 27" × 30" (0.69 m × 0.76 m) |
| Certifications | ANSI/SAIA A92.3, CE EN 1570-1, CSA |
| Machine Weight | 680 lbs (308 kg) |
| Working Height | 31 ft (9.45 m) |
| Platform Height | 25 ft (7.62 m) |
| Platform Capacity | 300 lbs (136 kg) |
| Outrigger Footprint | 66" × 66" (1.68 m × 1.68 m) |
Multi-angle views of the Genie IWP-25S Indoor Work Platform. Click any image to zoom.
See this class of lift in action. The video below shows installation, real-world operation, and the kind of shop this lift belongs in.
⚙️ Full-Cage Platform with D-Ring Anchor
Full-perimeter cage with self-closing positive-latch gate meets OSHA 1910.29 and ANSI/SAIA A92.3 fall protection requirements. Operators must wear a full-body harness with a lanyard connected to the D-ring fall arrest anchor at all times while elevated — the anchor is rated for the full OSHA 5,000 lb fall arrest load.
🔒 Tilt / Slope Interlock
An electronic inclinometer prevents mast extension on slopes beyond the rated threshold. If the machine moves onto an unlevel surface while elevated, all motion halts immediately. On push-around units, the interlock also prevents outrigger-free ascent — the machine cannot be "tilted up" by lifting a foot.
📐 Mechanical Outrigger Interlock
All four outrigger feet must confirm floor contact before the mast will ascend above the low-profile travel position. This interlock is implemented in the hydraulic circuit on most models — not software — making it physically impossible to bypass without mechanical modification.
🛡️ Emergency Descent System
A gravity-fed or mechanical emergency descent system lowers the mast to ground level without electrical power. The emergency descent valve is accessible from outside the cage and clearly labeled. All personnel lift operators must know the location and operation of the emergency descent before use.
How does this compare?
The IWP-25S is the professional upgrade from the AWP series — bigger cage, more capacity, better outrigger stability, and continuous-position locking for precise height setting. If you're running 10+ hours of facility maintenance per day, the IWP's heavier construction pays off in durability. For facilities that need to move the lift between floors, the 680-lb weight is light enough for most standard freight elevators (1,000 lb minimum). Need self-propelled repositioning at height? Step up to the JLG 20MVL.
